| Material: | BK7 Glass, UVFS |   |
||
| Flatness: | l/10 @ 632.8 nm | |||
| Wave range: | 400-2000 nm for BK7 200-2000nm for UVFS |
|||
| Bevel: | 0.25x45° mm | |||
| Part No. | Material | C.A. (mm) | Length (mm) | Retardation |
| FRP1101 | BK7 | 10 | 37 | l /4 |
| FRP1102 | BK7 | 10 | 37 | l /2 |
| FRP1103 | F.S. | 10 | 37 | l /4 |
| FRP1104 | F.S. | 10 | 37 | l /2 |
