Collimator

Baseline Collimator
Baseline collimator is widely used for optical axis calibration, and for infinity target collimation. It is a basic instrument in optical assembly.


P/N Focal length C. A. Resolution Field Angle
C120-A 120mm φ30mm 4.6” 8°
C200-A 200mm φ30mm 3.5” 8°
C500-A 500mm φ50mm 2.8” 3°
C1000-A 1000mm φ100mm 1.3” 1.5°
C1500-A 1500mm φ150mm 0.9” 1.7°

Large Field Angle Collimator
Large filed angle collimator is widely used for optical imaging alignment. The most application is for Head-up display collimation, Head-mounted display collimation, wide-angle imaging collimation, etc. It can measure positional accuracy, angle of deviation, plotting scale, imaging distortion, and other specs.

P/N Focal length C.A. Field Angle Scale Value
G30060 280mm φ60mm 30° 10’
G30100 300mm φ100mm 30° 10’
G30150 550mm φ150mm 30° 10’
G40160 420mm φ163mm 40° 10’
G40190 420mm φ190mm 40° 10’
